Topsec's Next-Generation Firewall system

TOPSEC NGFW is a next-generation firewall launched by TOPSEC, offering comprehensive security capabilities while delivering strong hardware performance.

Product Overview

Topsec's next-generation firewall system integrates an AI-driven intelligent detection engine, combining multiple security modules including intrusion prevention, WAF, botnet/malware protection, URL filtering, DDoS mitigation, HTTPS traffic inspection, advanced threat protection, anomalous behavior analysis, DLP, and threat intelligence. By collaborating with cloud, network, and endpoint elements, it delivers a comprehensive, proactive, and intelligent protection solution featuring AI-powered point defense, multi-dimensional coordination, and cloud detection capabilities, ensuring security coverage with "zero" blind spots for users.

Activity & Announcement
Advantages
AI-Powered Intelligent Detection Engine

Equipped with an AI-driven integrated intelligent detection engine, it can handle traditional security tasks such as antivirus and intrusion prevention, while also detecting DGA domains, covert channels, and malicious encrypted traffic to block their communication processes. This effectively defends against various advanced threats that were previously difficult to detect.

Comprehensive Asset Management

It features one-click asset scanning and discovery, asset import/export, manual asset entry, asset linkage reporting, and asset grouping. Based on specified network ranges, assets and their types can be identified through automatic and manual recognition methods. Building on asset identification, it provides asset risk assessment and behavioral tracking, ultimately helping administrators achieve asset protection and reinforcement.

Integrated Web Application Protection

The WAF security engine can issue risk warnings and intercept requests from malicious crawlers, effectively preventing server CPU spikes and website service interruptions caused by such crawlers. Additionally, the WAF security engine enhances capabilities such as hotlink protection, cross-site request forgery prevention, and application hidden protection.

Integrated Botnet, Trojan, and Worm Defense

Equipped with an independent detection and defense engine for botnets, Trojans, and worms, it features two rule databases: one for botnet, Trojan, and worm signatures, and another for botnet network characteristics. This engine not only detects and defends against emerging malicious code such as zombie viruses, Trojans, and worms but also monitors external botnet attacks in real-time. Based on configured policies, It actively alerts and blocks botnet attacks.

Threat Map and Attack Traceability

It not only displays threat maps across different geographic locations based on IP address databases but also allows the configuration of different access control policies for various regions. Additionally, it supports attack traceability, enabling continuous monitoring of persistent threats and effective blocking of attack sources, significantly reducing the impact of security incidents on user assets.

Intelligent Management and Security Operations

TOPSEC's next-generation firewall offers intelligent operation and maintenance tools, including security monitoring, data center, policy management, and Centralized Management. It simplifies security management by supporting one-click policy rollback, traffic reachability analysis, and rule simulation based on traffic parameters.

Applications
Scenario

Data Center Scenario

For east-west security isolation and access control within a single critical zone (e.g., database or application server cluster) in a data center.

Enterprise Boundary Scenario

Serves as the Internet egress gateway for medium-sized enterprises or large branch offices, securing inbound and outbound user traffic.

Branch Office Scenario

Acts as the local security core for regional or major city branches, handling both Internet access and dedicated line traffic to headquarters.

Value to Customers
Real-Time Network Visibility

Rich visualization of traffic and threat trends helps users understand network conditions.

Enhance Advanced Protection Capabilities

Integrates multiple security engines and advanced protection features to provide comprehensive security defense.

Streamline Operations with Intelligent Management Tools

Offers a wide range of platform-based and intelligent management tools to reduce the cost of security operations.

Specification
0 > 0 > 0 > 0 > 0 > 0 >
Performance MTG- C3106-E MTG-C4107-E MTG-C6212-E NG-61512-E NG-61712-E
Firewall Throughput 0.8Gbps 1.5Gbps 5Gbps 12Gbps 18Gbps
Concurrent Sessions 500,000 500,000 2,000,000 3,000,000 4,000,000
New Sessions/Sec 10,000 12,000 22,000 70,000 90,000
Application Control Throughput 600Mbps 1Gbps 3Gbps 10Gbps 15Gbps
AV Throughput 400Mbps 450Mbps 750Mbps 1.8Gbps 2Gbps
IPS Throughput 450Mbps 600Mbps 900Mbps 1.8Gbps 2Gbps
Threat Protection Throughput 300Mbps 350Mbps 600Mbps 1.5Gbps 1.6Gbps
IPsec VPN Throughput 200Mbps 300Mbps 500Mbps 1Gbps 1Gbps
Max IPsec VPN Tunnels 100 100 1000 2000 2000
Form Factor Desktop 1U 1U 1U 2U
RAM 4G 4G 4G 16G 16G
Management Ports 1 × Console Port, 2 x USB 2.0 Ports 1 × Console Port, 2 x USB 2.0 Ports 1 × Console Port, 2 x USB 2.0 Ports 1 × Console Port, 2 x USB 2.0 Ports 1 × Console Port, 2 x USB 2.0 Ports
Fixed I/O Ports 6 x GE 5 x GE, 2 x SFP 8 x GE , 2 x SFP , 2 x SFP+ 8 x GE , 2 x SFP , 2 x SFP+ 8 x GE , 2 x SFP , 2 x SFP+
Available Slots for Expansion Modules - - 1 2 2
Dimensions (W × D × H, mm) 260×180×44 426×300×44 426×375×44 440×510×44 440×510×89
Power Specification 36W,Single AC 60W,Single AC 60W,Single AC 150W, Dual AC 150W, Dual AC
Power Supply AC 100-240V,50/60 Hz AC 100-240V,50/60 Hz AC 100-240V,50/60 Hz AC 100-240V,50/60 Hz AC 100-240V,50/60 Hz
Weight 1.3Kg 3.15Kg 4.12Kg 10Kg 10Kg
Working Temperature 0~40℃ 0~40℃ 0~40℃ 0~40℃ 0~40℃
Relative Humidity 20-90%,Non-Condensing 20-90%,Non-Condensing 20-90%,Non-Condensing 20-90%,Non-Condensing 20-90%,Non-Condensing
